Transit Communications Offshore Oil & Gas Rig Moves
Offshore rigs transit voyages between Oil &Gas World regions
Red C
Transit Communication Solution
Offers Global C band broadband full managed services
All plans include:
Automatic Beam Switching (ABS)
Time Division Multiple Access (TDMA)
Committed Information Rate (CIR)
Out of Band Management (OBM)
Equipment:
Stabilized antennas C-Bird
Modems iDirect
Red C
Global Coverage
Red C
Global CIR and why is so important?
Committed Information Rate (CIR) is guaranteed bandwidth that is not shared by other clients on the network. It guarantees communications when the network is heavily loaded
How much CIR do the RedCGlobal plans have?
They include 64 Kbps, 128 Kbps, 256 Kbps CIR options
Global C
Global ABS and Why is so important?
To do it properly requires multiple satellites with wide geostationary separation with overlapping beams. RedCGlobal network uses:
Five satellites with overlapping coverage in the America spread over 75 degrees of longitude
Two satellites with overlapping coverage in the AOR spread over 26 degrees of longitude
Six satellites with overlapping coverage in Europe spread over 99 degrees of longitude
ABS is used to solve blockage issues, whether onboard or nearby. If you only have two satellites close together both may be blocked
What triggers ABS?
GPS position indicates the vessel is approaching the footprint edge
Antenna azimuth (to the satellite) approaching a mapped blockage zone
Reduction of SNR (Signal to Noise Ratio)
OBM command and control ability
ABS is not instantaneous. A new option file is pushed to the modem and the iDirectmodem needs to reboot.
Red C
Global Plan Specifications
New Installations or Conversions with C-BirdTMantenna
Coverage Area includes Americas, Australia, Asia, POR, Caribbean, AOR, Europe, Mediterranean, East and West Coast Africa
Multiple Satellites in most areas provides layered coverage for redundancy and ABS solutions
Three options with Committed Information Rate
64 Kbps CIR
128 Kbps CIR
256 Kbps CIR
Red C
Global Service Flexibility
Premium VSAT service within your budget during transit
Antenna kit ready for crew assembly in port, no crane required. Lighter weight for easy rig prep.
Exceptional C band global coverage
Unlimited Data, Internet , Enterprise Quality Voice, and Television (Q4 2013)
Operating contract during transit, and once at operation site it could continue as back up to Ku band alternatives, or separate crew calling system, or TV entertaining / training at site service.
Global Value Added Services
In-cabin crew calling and internet
No inventory of crew calling cards
Real time/online accounting of crew calling
Real time/online accounting of crew calling
–(Available Q4 2013)
Telemedicine *
–(Quoted separately with CIR 128 Kbps or 256 Kbps options)
Roaming & WiFi OnMarine*
Services not included in table rates to be quoted separately
OnMarine Services
Roaming On Marine enables users on offshore installations to use their mobile phones in the same way they do on land
Costs are in line with international roaming rates as appear on individual monthly mobile phone bills
Roaming OnMarinesupplies the roaming infrastructure which allows people to use their mobile phones, smartphonesand tablets in the same way as international roaming
Bandwidth required min. 32 Kbps up to 256 Kbps depending on simultaneous number of calls
WiFi On Marine enables users to connect to the Internet from laptops, tablets and smartphonesover WiFiby simply launching their browser as they would in any hotspot
WiFi On Marine homepage then guides them through the process
Homepage customized in several languages
Major credit cards are acceptedOnMarineServices
How Roaming On Marine Works
Mobile phones or smartphoneson-board are used as they do on land
Miniature cell base station picks up the signal
Signal is processed by the on-board GSM server
Signal is transmitted via RedCsatellite link
Ground GSM infrastructure process signal and directs traffic to called party,
The reverse path from land to vessel is the same vice versa
Red CGlobal Hardware
Red C Global C-Bird ® 2.4 m Antenna
Non critically balanced stabilized antenna
2.4 mtsdish, Intelsat certified
Extended C band coverage with Circular polarization
All motors, connectors and all electronics have environmental protection (IP65)
Specially coated to resist rust and chipping
Automatically locks in wind over 85 knots
Strong performance/reliability in deep ocean
Red C Global C-bird ® Installation
Antenna kit assembled by crew in few hours
No shore crane or special tools required
All indoor and outdoor cabling included
Voice Gateway, telephone handsets provides
System commisionedwith one key stroke
Automatically locks in wind over 85
Small indoor footprint equipment with cabinet prewired
Red C Summary
Robust Global ABS & Professional CIR plans for the Oil & Gas Transits
Easy installation on dock or on transit which could be performed by crew
Layered overlapping satellite coverage for reliability and redundancy
Plans choice with great flexibility for main or complementary services, on transit of final destination
Crew Welfare, Morale & Retention improvement
Competitively priced TDMA solution designed for crews for rig moves or transits
One SIMPLE Global Price
One STOP Shopping for all your transit and after relocation needs
